    Mini Mill Pulverizer Powder Grinder Machine WFJ Series High Efficiency

    Ask Lasest Price
    Brand Name : Xinda
    Model Number : WFJ-60
    Certification : ISO CE
    Supply Ability : 10 Piece/Pieces per Month
    Price : Negotiable
    • Product Details
    • Company Profile

    Mini Mill Pulverizer Powder Grinder Machine WFJ Series High Efficiency

    Mini Mill Pulverizer Powder Grinder Machine WFJ Series High Efficiency


    Xinda 2020 WFJ Series Mini Mill Pulverizer


    Main application
    (1) The machine is composed of main motorauxiliary motor and electricalcontrol cabinet with the capabilities of winnowing, nonsieve or Meshcompact design and reasonable structure.
    (2) Due to the negative pressure sends heat out continuously in operation, the machine is also applied for the grinding of heat sensitive materials.
    (3) The pulverizer is widely applied in industries such as chemical foodstuff, pharmacy, cosmetic, tincture resin andso on, ranking world advanced levels.
    Working method
    (1) Raw material is delivered to the grinding chamber via hopper by spiralfeeder, and is cut and sheared by the high speed cutters, then the Materialis moved into the whirlwind separator and sack dust catcher by the negative pressure sucking method.
    (2) The dust is collected And recycled via cloth bag or filter of dust absorption box.
    (3) There is no dust flying during production so as to improve the utilization and Decrease the production cost.


    ModelModel30Model60
    Capacity(kg/h)30-80050-1200
    Size of input granules(mm)< 15< 20
    Size of output granules80-320(adjustable)80-320(adjustable)
    General power(kw)4684.15
    Main running speed(r/min)38002800
    Weight(kg)23003200
    Overall size(mm)(L× W× H)6640× 1300× 39607500× 2300× 4530
